MCB DISTRIBUTION BOX
Product Catalogue & Performance Details Format For Export / OEM / Dealer Presentation
Safe • Durable • IEC Compliant
Suitable for Residential, Commercial & Industrial Applications
About Product
MCB Distribution Boxes are designed for safe distribution and protection of electrical circuits using MCBs,
RCCBs, Isolators and other modular devices. These boxes provide shock protection, fire safety and organized
power distribution for residential, commercial and industrial installations.
Manufactured using high-quality CRCA steel / ABS plastic with powder-coated finish for long service life and
corrosion resistance
Product Overview
| Parameter | Specification |
|---|---|
| Product Type | SPN Distribution Box |
| Number of Ways | 4 / 6 / 8 / 12 / 16 Way |
| Rated Voltage | 240V AC |
| Rated Frequency | 50/60 Hz |
| Rated Current | Up to 125A |
| Material | CRCA Steel / ABS Plastic |
| Mounting Type | Flush / Surface |
| Degree of Protection | IP42 / IP43 |
| Busbar Material | Copper / Aluminium |
| Finish | Powder Coated |
| Color | White / Grey |
| Door Type | Transparent / Metal |
| Standard Compliance | IEC 61439 |
| Neutral Link | Provided |
Product Features
• Strong CRCA steel construction
• Shock-proof design
• Corrosion-resistant powder coating
• Easy wiring and installation
• Removable gland plates
• High mechanical strength
• Proper ventilation design
• Smooth door operation
• Copper busbar option available
• Suitable for modular MCBs
| Test Parameter | Performance |
|---|---|
| Mechanical Strength | Excellent |
| Heat Resistance | High |
| Corrosion Resistance | Excellent |
| Electrical Insulation | Reliable |
| Door Operation Life | Long Life Performance |
| Busbar Conductivity | High Efficiency |
| Mounting Stability | Secure Installation |
| Wiring Space | Adequate |
Applications
• Residential Buildings
• Commercial Complexes
• Offices
• Factories
• Retail Shops
• Hospitals
• Schools
• Industrial Panels
PERFORMANCE DETAILS
TPN Distribution Box
Product Overview
TPN Distribution Boxes are designed for three-phase power distribution systems and provide safe mounting for MCBs, MCCBs and isolators used in industrial and commercial applications.
| Parameter | Specification |
|---|---|
| Product Type | TPN Distribution Box |
| Number of Ways | 4 / 6 / 8 / 12 Way |
| Rated Voltage | 415V AC |
| Rated Frequency | 50/60 Hz |
| Rated Current | Up to 250A |
| Pole Configuration | Triple Pole & Neutral |
| Material | CRCA Steel |
| Mounting Type | Surface Mounted |
| Protection Class | IP42 / IP54 |
| Finish | Powder Coated |
| Busbar | Copper / Aluminium |
| Standard | IEC 61439 |
Features
• Heavy-duty construction
• Three-phase load distribution
• Safe busbar arrangement
• High insulation strength
• Long service life
• Easy maintenance
• Strong door locking system
• Suitable for industrial applications
